螺紋
Thread
|
編號(hào)
P/N
|
T(GRIP RANGE) Min Max |
A Rer |
Hole Size +0.1 |
D +0.07 -0.1 |
B | K | L |
| M3 | FH-KB/SS-0315 | 0.5-1.5 | 5.0 | 5.0 | 4.9 | 8.0 | 0.8 | 9.0 |
| M4 | FH-KB/SS-0420 FH-KB/SS-0440 |
0.5-2.0 2.0-4.0 |
6.5 | 6.0 8.0 |
5.9 | 9.0 | 0.8 | 10.5 12.0 |
| M5 | FH-KB/SS-0525 FH-KB/SS-0540 |
0.5-2.5 2.0-4.0 |
8.0 8.5 |
7.0 | 6.9 | 10.0 | 1.0 | 13.0 15.0 |
| M6 | FH-KB/SS-0630 FH-KB/SS-0650 |
0.5-3.0 3.0-5.0 |
9.2 10.5 |
9.0 | 8.9 | 12.3 | 1.3 | 15.5 19.5 |
| M8 | FH-KB/SS-0835 FH-KB/SS-0855 |
1.0-3.5 3.5-5.5 |
11.5 | 11.0 | 10.9 | 14.5 | 1.5 | 18.5 21.5 |
| M10 | FH-KB/SS-1040 FH-KB/SS-1060 |
1.0-4.0 4.0-6.0 |
13.5 | 13.0 | 12.9 | 17.0 | 1.6 1.7 |
21.0 24.0 |
| M10 | FH-KB/SS-1040 FH-KB/SS-1060 |
1.0-4.0 4.0-6.0 |
15.0 16.0 |
16.0 | 15.9 | 23.0 | 2.0 | 25.0 28.0 |
